Fast gravel, rough gravel, pavement or dirt. However you choose to roll, this bike does it all. A new composite frameset and adjustable wheelbase make it more capable than ever.
With a lightweight Advanced-grade composite frame that's engineered for compliance, Revolt Advanced lets you push your limits on variable terrain. A composite fork eats up bumps, and the D-Fuse seatpost and handlebar absorb shocks and vibrations. A flip chip on the rear dropout adjusts wheelbase and tire clearance, and you can choose the included D-Fuse seatpost for maximum compliance or a 30.9mm round or dropper post. Details including a smart mount system for racks and accessories give you a head start on any gravel riding mission
Specs
Frame Advanced-Grade Composite, 12x142mm thru-axle, disc, flip chip dropout
Fork Advanced-Grade Composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Rims Giant P-X2 Disc wheelset
Hubs Giant P-X2 Disc wheelset
Spokes Giant P-X2 Disc wheelset
Tires Maxxis Rambler, 700x45c, tubeless
Bottom Bracket SRAM DUB, press fit
Crankset SRAM Rival D1 DUB, 40t XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Shifters SRAM Rival eTap AXS, 1x12
Rear Derailleur SRAM Rival eTap AXS XPLR
Cassette/Freewheel SRAM Rival, 12-speed, 10x44
Chain SRAM Rival D1
Brakes SRAM Rival eTap AXS hydraulic, Giant MPH rotors [F]160mm, [R]140mm
Brake Levers SRAM Rival eTap AXS hydraulic
Handlebars Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Tape/Grips Stratus Lite 3.0
Stem Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Seatpost Giant Contact Switch, dropper, 30.9mm XS:295mm, S:345mm, M:345mm, M/L:345mm, L:395mm, XL:395mm
Saddle Giant Approach
Pedals Sold Separately
Accessories & Extras Giant 1x chain guide, tubeless prepared, 53mm max tire size in "long" flip chip position, 42mm max tire size in "short" flip chip position
