Specifications
Display
Backlight Color Pure white LED
Display Resolution 800 x 480
Display Size 7 inches
Screen Brightness 1000 NITS
Viewing Angles 80° top/bottom, 80° left/right
Connectivity
SD Card Storage 1 slot (microSD® 32 GB maximum)
Cartography
Charts supported C-MAP® DISCOVER™.
Electrical
Power Consumption max 550 mA @ 12 V DC with backlight on full
Power Consumption min 250 mA @ 12 V DC with backlight off
Power Consumption typical 550 mA @ 12 V DC with backlight on full
Recommended Fuse Rating 3A
Supply Voltage 12v DC (10.8-17VDC)
Environment
Humidity 60°C, 95% relative humidity (RH) for 48 hours
Operating Temperature Range 5°F to 131°F (-15°C to 55°C )
Storage Temperature Range 4°F to 140°F (-20°C to 60°C )
Waterproofrating IPX7 with card door closed
GPS
Correction SBAS
Time to First Fix 45s
MFD
Cartography included C-MAP® Discover OnBoard™ charts for the US and Canada
Waypoints, Routes, Tracks 3000 Waypoints 100 Routes 100 Trails
Physical
Compass Safe 12" (300mm)
Dimensions W x H x D 225.9 mm (8.89") x 139.8 mm (5.5") x 88.5 (3.48)
Mounting Type Gimbal bracket or dash mount
Weight 0.67 kg (1.48 lb)
Other
Interface Keypad:8-way directional keypad, Zoom +/- (MOB), Exit, Enter, Menu, Waypoint, Power / backlight
Warranty Period 1 Year + 4 additional years of upgrade options totaling 5 years
